AKYAPAK / 3 ADM -1200

  • Main Specification Description

    Please refer to the below

  • Performance

    CNC Multi-Drilling Machine

SPECIFICATIONS

  • Capacity

    Max. H1200 x 500 / Min. H100 x 100

  • Drilling Size

    Φ10 ~ Φ40 (Carbide) / Φ10 ~ Φ50 (U-drill)

  • No. of Spindles

    WEB : 1EA / FLG : 1EA x 2

  • Speed of Spindle

    50 ~ 3000rpm stepless

  • Power of Spindle

    22kw

  • Automatic Tool Changer

    1 ATC with 4 tools for each spindle
